JAI Spark Series SP-45001M-CXP4

Highlights

The JAI Spark Series SP-45001M-CXP4 provides the same 44.7-megapixel monochrome resolution as the SP-45000M-CXP4 but uses a reduced-speed version of the OnSemi XGS 45000 CMOS imager. This results in a list price that is more than 20 percent lower for customers not needing the ultra-high performance of the full speed models. It offers the same high image quality and special functions as the higher-speed models, making it well suited to a wide range of high-resolution applications.

With a maximum full resolution frame rate of 38 fps for 8-bit images and 32 fps for 10-bit or 12-bit images, the SP-45001-CXP4 provides ample speed to support a wide range of high-resolution applications where ultra-high performance is not required. The lower price point enables vision system designers to maximize the cost competitiveness of their systems, especially for applications where multiple high-resolution cameras are utilized. The JAI Spark Series SP-45001M-CXP4 comes with Built-in functions for HDR imaging, with an exceptionally low dark noise rating (<5e-), the SP-45001-CXP4 boasts 67 dB of standard dynamic range, extendable to 73 dB by built-in linear or knee-point HDR functions for both monochrome and color models. For applications that demand the highest possible image quality, the SP-45001-CXP4 features a Frame Integration mode that can average the exposures of up to 8 sequential frames to dramatically reduce the amount of shot noise in the image.

The Spark Series

JAI provides a wide selection of single-sensor color area scan cameras with resolutions ranging from 2.35 to 45 megapixels. Cameras are built around state-of-the-art sensor technology including the latest CMOS global shutter imagers. For maximum imaging performance, JAI’s Spark Series cameras are the ideal choice. These CMOS cameras are designed to provide an optimal blend of speed, resolution, and supreme image quality. For maximum imaging performance, JAI’s Spark Series cameras are the ideal choice. These CMOS cameras are designed to provide an optimal blend of speed, resolution, and supreme image quality.

JAI Spark Series SP-45001M-CXP4 Features

  • 44.7-megapixel resolution at 52 fps.
  • 8K resolution (7680 x 4320) at over 65 fps.
  • Compact 31.5 mm sensor diagonal with 3.2-micron square pixels.
  • Global shutter CMOS imager for no motion-related distortion.
  • Monochrome output with 67 dB of standard dynamic range.
  • Built-in HDR functions provide up to 73 dB of HDR as 14-bit linear output or 8/10/12-bit knee-point compressed images.
  • Single ROI and multi-ROI modes with up to 64 defined regions.
  • Lens control function for utilizing Birger Mount via RS-232C lens control commands
  • Edge enhancer function, plus vertical and horizontal image flipping.
  • Image sequencer plus frame integration modes for noise reduction or HDR.
  • Automatic Level Control (ALC) for dynamic lighting conditions.
  • Four-channel CoaXPress v1.1 interface supporting up to 6.25 Gbps per lane.
  • Can share processing across multiple PCs via the CoaXPress link sharing function.
  • Industrial grade performance with 80G shock and 10G vibration rating.
