Video formats @ frame rate (maximum)
4,128×3,096 (12.8 MP) YUY2 @ 1 fps | 3,264×2,448 (8 MP) YUY2 @ 1 fps | 2,592×1,944 (5 MP) YUY2 @ 1 fps | 1,920×1,080 (2.1 MP) YUY2 @ 30 fps | 1,600×1,200 (1.9 MP) YUY2 @ 30 fps | 1,280×960 (1.2 MP) YUY2 @ 30 fps | 1,280×720 (0.9 MP) YUY2 @ 30 fps
-
IR cut filter
Yes
-
Sensor type
CMOS Exmor
-
Shutter
Rolling
-
Format
1/2.5 inch
-
Resolution
4,128×3,096
-
Frame Rate
30 fps
-
Megapixel
12.8 MP
-
Focal length
5.3 mm
-
F-Stop
2.8
-
MOD
10 cm
-
Focus
One touch
-
Interface
USB 3.0
-
Supply voltage
4.5 VDC to 5.5 VDC
-
Current consumption
approx 250 mA @ 5 VDC
-
Auto iris control
No
-
Trigger
No
-
I/Os
No
-
Dimensions
H: 29 mm, W: 29 mm, L: 39 mm
-
Mass
65 g
-
Shutter
1/5,000 s to 1 s
-
Gain
ISO 50 dB to ISO 3200 dB
-
White balance
presets: light bulb, daylight color, fluorescent light, clear sky, cloudy sky, neutral color fluorescent light, light bulb color fluorescent light modes: red adjustment, blue adjustment
-
Image processing
modes: sharpness, brightness, contrast
-
Color processing
modes: saturation, hue
-
HDR
modes: on, off, configurable options
-
Temperature (operating)
-5 °C to 55 °C
-
Temperature (storage)
-20 °C to 60 °C
-
Humidity (operating)
20 % to 80 % (non-condensing)
-
Humidity (storage)
20 % to 95 % (non-condensing)
