Orbbec Gemini 2 L Stereo Vision Camera

Orbbec Gemini 2 L is a long-baseline active stereo 3D camera designed for robotics, measurement, mapping, and industrial automation. It combines a 100 mm stereo baseline with Orbbec MX6600 depth processing, dual global-shutter imaging, an integrated IMU, and USB Type-C connectivity.

The Gemini 2 L provides depth resolution up to 1280 × 800 at 30 fps, a 0.20 m to 10 m depth range, and a wide 91° × 66° depth field of view. An integrated 940 nm proximity sensor provides close-distance single-point ranging to reduce blind spots, while multi-camera synchronization supports wider-area and multi-angle 3D vision systems.

100 mm Stereo Baseline
— Long-baseline stereo geometry supports accurate depth measurement and 3D reconstruction at extended working distances.

Close-Range Proximity Sensing
— An integrated 940 nm proximity sensor provides single-point ranging at close distances to help eliminate depth blind spots.

Dual Global Shutter Imaging
— Global-shutter depth and RGB sensors minimize motion distortion in dynamic robotic and automation applications.

Wide Field of View
— 91° × 66° depth coverage captures broad scenes for navigation, mapping, interaction, and measurement.

Integrated 6 DoF IMU
— Motion and orientation sensing supports robotic localization, tracking, and navigation.

Multi-Camera Synchronization
— An 8-pin hardware synchronization interface supports multi-angle and wide-area 3D vision configurations.
