Imperx Puma POE-P1320I VIS-SWIR Camera

Highlights

The Imperx Puma POE-P1320I is a 1.31 MP VIS-SWIR CMOS area scan camera designed for imaging across visible and short-wave infrared wavelengths. Its Sony SenSWIR IMX990 global-shutter sensor provides a native resolution of 1296 × 1032 pixels, spectral coverage from 400 nm to 1700 nm, and acquisition at up to 71.4 frames per second.

GigE Vision connectivity with Power over Ethernet supports camera power, control, and image transmission through a network connection. The POE-P1320I combines ruggedized construction, raw-data access, automatic exposure and gain control, multiple LUTs, programmable trigger and strobe functions, flexible lens-mount options, and an optional integrated cooling pipe.

Features

• 1.31 MP resolution with a native image size of 1296 × 1032 pixels
• Sony SenSWIR IMX990 sensor with global-shutter CMOS technology
• 400–1700 nm spectral coverage for visible and short-wave infrared imaging
• Up to 71.4 fps at the camera’s native resolution
• GigE Vision connectivity for network-based image transmission and camera control
• Power over Ethernet support for streamlined system integration
• 1/2-inch optical format for compact VIS-SWIR imaging systems
• Ruggedized construction as the standard environmental configuration
• Flexible lens mounting with C-mount standard and optional CS and P-Iris configurations
• Raw-data access without mandatory image corrections
• Automatic exposure and gain for changing imaging conditions
• Multiple LUTs with user-selectable image corrections
• Trigger and strobe support for synchronized image acquisition
• Optional integrated cooling pipe for application-specific thermal management

Applications

• Electronic board inspection
• Solar-cell inspection
• Semiconductor and integrated-circuit inspection
• Material identification and sorting
• Foreign-substance contamination detection
• Opaque-container content and fill-level inspection
• Water and oil contamination detection
• Agricultural and food-condition monitoring
• Coating inspection and process control
• Surveillance imaging
• Anti-counterfeiting inspection
• Process quality control
