Frame Rate
149 fps
-
Lens Mount
S-mount
-
Pixel Size
4.8
-
Resolution
1280 × 1024
-
Sensor
1/2" ON Semi PYTHON 1300 CMOS
-
ADC
10-bit
-
Chroma
Color
-
Megapixel
1.3 MP
-
Readout Method
Global Shutter
-
Compliance
CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
-
Machine Vision Standard
USB3 Vision v1.0
-
Operating Humidity
20 to 80% (no condensation)
-
Operating Temperature
0° to 45°C
-
Storage Humidity
20 to 95% (no condensation)
-
Storage Temperature
-30° to 60°C
-
Image Processing
Gamma, lookup table, hue, saturation, and sharpness
-
Flash Memory
1 MB non-volatile memory
-
Image Buffer
16 MB
-
Trigger Modes
Standard, bulb, multi-shot
-
User Sets
2 user configuration sets for custom camera settings
-
Exposure Range
0.01 ms to 1 second
-
Gain Range
0 dB to 18 dB
-
Partial Image Modes
Pixel binning, decimation, ROI
-
Absolute Sensitivity Threshold (y)
21.39
-
Quantum Efficiency Blue
41 (% at 470 nm)
-
Quantum Efficiency Green
45 (% at 525 nm)
-
Quantum Efficiency Red
46 (% at 640 nm)
-
Saturation Capacity (e-)
6060
-
Temporal Dark Noise (e-)
8.90
-
Dynamic Range dB
56.19
-
Mass
27.9 grams
-
Auxiliary Output
3.3 V, 150 mA maximum
-
Interface
USB 3.1 Gen 1
-
Non-isolated I/O Ports
2 bi-directional
-
Opto-isolated I/O Ports
1 input, 1 output
-
Dimensions
40 mm × 31 mm (board level)
-
Power Requirements
5-24 V via GPIO or 5 V via USB3
-
Hard Drive
200 MB hard drive space
-
RAM
2GB RAM or more
-
Port
USB 3 Port
-
Operating System
Windows or Linux (32–bit or 64–bit)
-
CPU
3.1 GHz or equivalent CPU
