The Imaging Source DMK 36CX335-I67 Monochrome IP67 FPD-Link III Camera

Highlights

The Imaging Source DMK 36CX335-I67 Monochrome IP67 FPD-Link III Camera is a rugged 5 MP embedded vision camera built around the Sony IMX335 STARVIS CMOS sensor. It captures 2,592 × 1,944 monochrome images at up to 30 fps with 2.0 µm pixels and a rolling shutter.

Designed for demanding embedded vision applications, the DMK 36CX335-I67 combines high-resolution monochrome imaging with FPD-Link III connectivity and an IP6K6- and IP6K7-compliant enclosure measuring only 36 × 36 × 60.3 mm.

Features

• 5 MP resolution with an image size of 2,592 × 1,944 pixels.
• Up to 30 fps at full resolution.
• Sony IMX335 sensor based on STARVIS CMOS technology.
• Rolling shutter image acquisition.
• 2.0 µm pixels on a 1/2.8-inch sensor.
• 12-Bit and 10-Bit Monochrome output for grayscale imaging.
• 12-bit dynamic range.
• FPD-Link III interface via FAKRA connection.
• IP6K6 and IP6K7 protection under ISO 20653.
• Optional M12x0.5 lens mount.
• 20 µs to 0.5 s exposure range.
• 0–72 dB gain range.
• 10–27 VDC supply.
• Low power consumption of approximately 80 mA at 18 VDC.
• Compact rugged housing measuring 36 × 36 × 60.3 mm and weighing 80 g.

Applications

• Embedded vision systems
• Industrial automation
• Robotics
• Machine vision
• Monochrome inspection
• High-resolution imaging
• Computer vision
• Outdoor imaging
• Multi-camera systems
• Harsh-environment machine vision
