The Imaging Source Industrial 33e DMK 33GX264e

Features

Dynamic range

8/12 bit
Video formats @ frame rate (maximum)

2,448×2,048 (5 MP) Y800 @ 24 fps | 2,448×2,048 (5 MP) Y16 @ 16 fps
IR cut filter

No
Sensor type

CMOS Pregius
Sensor specification

Sony IMX264LL
Shutter

Global
Format

2/3 inch
Resolution

2,448×2,048
Frame Rate

24 fps
Megapixel

5 MP
Lens mount

C (CS Optional)
Interface

GigE
Supply voltage

11 VDC to 13 VDC or POE: 48 VDC to 56 VDC
Current consumption

approx 400 mA @ 12 VDC
Auto iris control

No
Trigger

Yes
I/Os

Yes
Dimensions

H: 29 mm, W: 44 mm, L: 57 mm
Mass

120 g
Shutter

20 µs to 30 s
Gain

0 dB to 48 dB
Temperature (operating)

-5 °C to 45 °C
Temperature (storage)

-20 °C to 60 °C
Humidity (operating)

20 % to 80 % (non-condensing)
Humidity (storage)

20 % to 95 % (non-condensing)
