Schneider Optics Sapphire 0.007/0.07x V70

Highlights

The Sapphire Series, Sapphire 0.007/0.07x V70 features highspeed lenses that are optimized for 16k / 3.5 µm and 12k / 5µm (SAPPHIRE XL: 16 k / 5µm) line scan sensors but also can be used in many applications with area sensors up to 82 mm diagonal. Optimized for a specific magnification of 0.07x – 2.0x the lenses providing high performance in a compact and robust package. The V70-Mount interface makes it easy to install numerous mounts and allows the rotation of the lens into the best azimuth.

Features

• Extremely high resolution down to 3.5µ pixel size
• Image circle: 62.5 mm – 82 mm
• Optimized for specific magnifications
• 11 magnifications available: 0.07x – 2.0x
• Version with Beamsplitter available
• Best azimuth marking
• V70-Mount for easy installation

Applications

• FPD inspection
• PCB inspection
• High resolution defect detection
• AOI (Automated Optical Inspection)
