Schneider Optics Emerald 4.0/80 F


The Emerald Series, Emerald 4.0/80 F features compact and fast lenses with image circles ranging from 43.2 mm up to 90 mm are designed for large area and line scan sensors. The robust mechanics and a special focus setting and locking mechanism ensures highest mechanical stability even in harsh environment.


  • Image circle: 43.2 mm – 90 mm
  • 5 focal lengths: 28 mm – 100 mm
  • F-Mount lens and V48-Mount lens available
  • Covering a wide working distance range
  • Initial apertures: F2.2 – F5.6


  • Machine Vision
  • AOI (Automated Optical Inspection)
  • 3D and 2D measurement
  • Traffic and surveillance

Product Specifications

Schneider Optics
Schneider Optics Emerald 4.0/80 F-Photo-1
