Frame Rate
48 fps
-
Lens Mount
C-Mount
-
Pixel Size
5.86
-
Quantum Efficiency
77 (Mode 0) / 77(Mode 7) (% at 525 nm)
-
Resolution
1920 × 1200
-
Sensor
1/1.2" Sony IMX174 CMOS
-
ADC
10-bit, 12-bit
-
Chroma
Mono
-
Megapixel
2.3 MP
-
Readout Method
Global Shutter
-
Compliance
CE, FCC, KCC, RoHS, REACH. The ECCN for this product is: EAR099
-
Machine Vision Standard
GigE Vision v1.2
-
Operating Humidity
20 to 80% (no condensation)
-
Operating Temperature
0° to 50°C
-
Storage Humidity
20 to 95% (no condensation)
-
Storage Temperature
-30° to 60°C
-
Image Processing
Gamma, lookup table, hue, saturation, and sharpness
-
Serial Port
1 (over non-isolated I/O)
-
Acquisition Modes
Single Frame Multi Frame Continuous
-
Flash Memory
2 MB non-volatile memory
-
Image Buffer
128 MB
-
Trigger Modes
Standard, bulb, overlapped, multi-shot
-
User Sets
2 user configuration sets for custom camera settings
-
Exposure Range
0.017 ms to 32 seconds
-
Gain Range
0 dB to 29.9 dB
-
Partial Image Modes
Pixel binning, ROI
-
Absolute Sensitivity Threshold (y)
20.42 (Mode 0) / 9.75 (Mode 7)
-
Saturation Capacity (e-)
32488 (Mode 0) / 32691 (Mode 7)
-
Temporal Dark Noise (e-)
14.74 (Mode 0) / 6.83 (Mode 7)
-
Dynamic Range dB
66.57 (Mode 0) / 72.99 (Mode 7)
-
Mass
90 grams
-
Auxiliary Output
3.3 V, 120 mA maximum
-
Interface
GigE PoE
-
Non-isolated I/O Ports
2 bi-directional
-
Opto-isolated I/O Ports
1 input, 1 output
-
Dimensions
44 mm × 29 mm × 58 mm
-
Power Requirements
Power over Ethernet (PoE), or 12 V nominal (8 - 24 V) via GPIO
-
Hard Drive
200 MB hard drive space
-
RAM
2GB RAM or more
-
Power Sourcing Equipment
PoE Interface Card / Injector/ Switch or Camera Power Supply(12v 1.5A, 8–pin Hirose)
-
Port
Gigabit Ethernet Port
-
Operating System
Windows or Linux (32–bit or 64–bit)
-
CPU
3.1 GHz or equivalent CPU
