Frame Rate
13 fps
-
Lens Mount
CS-mount (5 mm C-mount adapter not included)
-
Pixel Size
2.2
-
Resolution
2592 × 1944
-
Sensor
1/2.5" Aptina MT9P006 CMOS
-
ADC
12-bit
-
Chroma
Color
-
Megapixel
5 MP
-
Readout Method
Rolling shutter with global reset
-
Compliance
CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
-
Machine Vision Standard
GigE Vision v1.2
-
Operating Humidity
20 to 80% (no condensation)
-
Operating Temperature
0° to 45°C
-
Storage Humidity
20 to 95% (no condensation)
-
Storage Temperature
-30° to 60°C
-
Image Processing
Gamma, lookup table, and sharpness
-
Flash Memory
512 KB non-volatile memory
-
Image Buffer
16 MB
-
Trigger Modes
Standard, bulb, low smear, overlapped, multi-shot
-
User Sets
2 user configuration sets for custom camera settings
-
Exposure Range
0.03 ms to 32 seconds
-
Gain Range
0 dB to 18 dB
-
Partial Image Modes
Pixel binning, decimation, ROI
-
Absolute Sensitivity Threshold (y)
11.05
-
Quantum Efficiency Blue
53 (% at 470 nm)
-
Quantum Efficiency Green
52 (% at 525 nm)
-
Quantum Efficiency Red
50 (% at 640 nm)
-
Saturation Capacity (e-)
4769
-
Temporal Dark Noise (e-)
5.48
-
Dynamic Range dB
58.04
-
Mass
36 grams
-
Auxiliary Output
3.3 V, 120 mA maximum
-
Interface
GigE PoE
-
Opto-isolated I/O Ports
1 input, 1 output
-
Dimensions
29 mm × 29 mm ×30 mm
-
Power Consumption
2.5 W
-
Power Requirements
12 V nominal (5 - 16 V) via GPIO interface
-
Hard Drive
200 MB hard drive space
-
RAM
2 GB RAM or more
-
Power Sourcing Equipment
PoE Interface Card / Injector/ Switch or Camera Power Supply (12v 1.5A, 6-pin Hirose)
-
Port
Gigabit Ethernet
-
Operating System
Windows or Linux (32–bit or 64–bit)
-
CPU
3.1 GHz or equivalent CPU
