Frame Rate
41 fps
-
Lens Mount
C-Mount
-
Pixel Size
5.86
-
Resolution
1920 × 1200
-
Sensor
1/1.2 Sony IMX249 CMOS
-
ADC
10-bit, 12-bit
-
Chroma
Color
-
Megapixel
2.3 MP
-
Readout Method
Global Shutter
-
Compliance
CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
-
Machine Vision Standard
GigE Vision v1.2
-
Operating Humidity
20 to 80% (no condensation)
-
Operating Temperature
0° to 45°C
-
Storage Humidity
20 to 95% (no condensation)
-
Storage Temperature
-30° to 60°C
-
Image Processing
Gamma, lookup table, hue, saturation, and sharpness
-
Flash Memory
512 KB non-volatile memory
-
Image Buffer
16 MB
-
Trigger Modes
Standard, bulb, overlapped, multi-shot
-
User Sets
2 user configuration sets for custom camera settings
-
Exposure Range
0.019 ms to 32 seconds
-
Gain Range
0 dB to 29.9 dB
-
Partial Image Modes
Pixel binning, decimation, ROI
-
Absolute Sensitivity Threshold (y)
23.15
-
Quantum Efficiency Blue
60.25 (460nm)
-
Quantum Efficiency Green
59.7 (530nm)
-
Quantum Efficiency Red
37.91 (625nm)
-
Saturation Capacity (e-)
32291
-
Temporal Dark Noise (e-)
6.90
-
Dynamic Range dB
67.37
-
Mass
36 grams
-
Auxiliary Output
3.3 V, 120 mA maximum
-
Interface
GigE PoE
-
Opto-isolated I/O Ports
1 input, 1 output
-
Dimensions
29 mm × 29 mm ×30 mm
-
Power Consumption
2.5 W
-
Power Requirements
12 V nominal (5 - 16 V) via GPIO interface
-
Hard Drive
200 MB hard drive space
-
RAM
2 GB RAM or more
-
Power Sourcing Equipment
PoE Interface Card / Injector/ Switch or Camera Power Supply (12v 1.5A, 6-pin Hirose)
-
Port
Gigabit Ethernet
-
Operating System
Windows or Linux (32–bit or 64–bit)
-
CPU
3.1 GHz or equivalent CPU
