Euresys Coaxlink Duo PCIe/104-MIL

Highlights

The Euresys Coaxlink Duo PCIe/104-MIL is a two-connection military-grade ruggedized CoaXPress frame grabber. This frame grabber offers an extended operating temperature range, the ability to withstand high levels of shock and vibration, two CoaXPress CXP-6 (6 Gbit/s) camera connections, PCIe 2.0 (Gen 2) x4 bus, and is compliant with the PCIe/104 form factor.

Euresys Coaxlink Duo PCIe/104-MIL Features

  • Ruggedized COTS board for military applications
  • Sale subject to approval and export license. Please contact us for more information
  • Small stackable PCIe/104 form factor
  • Extended temperature range: -40 to +85°C / -40 to +185°F
  • MIL-STD-810G method 514.6 (vibration) and method 516.6 (shock)
  • Optional conformal coating
  • Two CoaXPress CXP-6 connections: 1,250 MB/s camera bandwidth
  • PCIe 2.0 (Gen 2) x4 bus: 1,700 MB/s delivery bandwidth
  • Compact size: 90 x 96 mm module size – reduced footprint for smaller electronic devices
  • Self-stacking: expands without backplanes or card cages
  • Rugged, reliable connectors: reliable in harsh environments
  • Four-corner mounting holes: resistance to shock and vibration
  • Fully PC compatible: reduced development costs and time-to-market
  • Backward compatibility with current PC/104 specifications and form factors
  • Commercial-Off-The-Shelf (COTS) for rapid uptime and low development costs
  • Interoperability across manufacturers

Euresys Coaxlink Duo PCIe/104-MIL Applications

  • Transmission and acquisition of high-definition video over long coaxial cables- CoaXPress is a recent powerful standard providing a high-speed interface between the camera and the PC frame grabber. On a highway, high-speed cameras can take images in a burst. The sharper images will enhance license plate recognition accuracy. High-frequency real-time triggering and exposure time adjustment to the low light situations can be accommodated.
  • Airborne ISR- Vision systems integrate high resolution and high-speed CoaXPress cameras for airborne intelligence, surveillance, and reconnaissance missions.
  • Camera turrets for airborne surveillance or gun turrets- CoaXPress cameras can easily be integrated into 360° rotating stations with slip rings to allow continuous panning. The high-resolution video provides sharper images and a larger viewing area thereby potentially reducing the number of cameras required.
  • Unmanned applications, vehicle-based video capture, remote control of UAVs- The CoaXPress standard allows video transfer to the PC in a few milliseconds. The very low latency of the system will allow the control of land vehicles or remote control of UAVs

Product Specifications

Euresys (Frame Grabbers)
Euresys Coaxlink Duo PCIe/104-MIL
