Smart Vision Lights SW75

Highlights

The Smart Vision Lights SW75 Brick Light is a spotlight that features a stainless-steel IP68-rated enclosure specially designed for the food industry and washdown environments. NPN or PNP trigger signal inputs can be used to control the pulse of the light. The intensity of the light can be controlled via 1-10VDC analog signal line or by adjusting the built-in manual potentiometer.

Smart Vision Lights SW75 Features

IP68 standards
Stainless-steel 316 housing with a silicone gasket
Acrylic and poly carb window options
PNP and NPN trigger signal input
FDA compliant for food manufacturing and corrosive environments

Smart Vision Lights Wavelength Chart 4

Product Specifications

Electrical Input

24VDC +/- 5%
Input Current

Max. 375 mA
Wattage

Max. 9.0 W
On/Off Input

PNP : +4VDC or greater to activate | NPN : GND (<1VDC) to activate
PNP Line

4 mA @ 4VDC | 10 mA @ 12VDC | 20 mA @ 24VDC
NPN Line

15 mA @ Ground (0 VDC)
Continuous Mode

NPN can be tied to ground OR PNP can be tied to 24VDC (not both).
Potentiometer

270º turn pot — intensity control of 10%–100%. Turn clockwise to increases intensity.
Analog Intensity

The output is adjustable from 10%–100% of brightness by a 1–10 V DC signal.
Connection

5-pin M12 connector
Ambient Temperature

-18º–40º C (0º–122º F)
IP Rating

IP68
Weight

~760 g
Compliances

CE, RoHS, IEC-62471
