Kaya Instruments IP Core Host


The Kaya Instruments IP Core Host provides a Multi-link high-performance solution for rate demanding video applications. Both Host and Device modes of operation are supported. The IP core offers support for the newest and industry-leading Artix, Kintex, Virtex, and Zynq FPGAs, including all 7, Ultrascale and Ultrascale+ families from Xilinx, Cyclone V, Cyclone 10, Arria V GX, Arria V GZ, Arria 10, Stratix IV, Stratix V and Stratix 10 FPGAs from Intel (former Altera) and PolarFire from Microsemi. The host IP core incorporates a friendly streaming interface with a highly configurable pixel packer for glueless connection to imaging sensors or uses logic.


  • High-speed cameras
  • High definition cameras
  • Frame Grabbers
  • Panoramic cameras
  • Upgrade for legacy coax based systems
  • Defense remote systems
  • Automotive surround view system
  • Surveillance
  • Robotic Vision


  • Compliant with JIIA NIF-001-2019 CoaXPress standard rev 2.0
  • CXP 2.0 support of up to 12.5 Gbps high-speed link and up to 41 Mbps low-speed link
  • Multiple link rates support
  • Supports both Host and Device modes
  • Multiple CoaXPress 2.0 links suited for applications demanding high throughput.
  • Multiple video stream support
  • Build-in FPGA SerDes, no need for the additional design effort
  • AXI4L/Avalon MM support for the control channel
  • Highly configurable pixel packer
  • Host IP Core supports multiple device connection on different data rates
  • Embedded CRC-32 generate/check for streaming data packets
  • Avalon and AXI4 Stream Interface Profile in Host IP Core
  • Dedicated ports for GPIO and trigger

Kaya Instruments IP Core Host Details

  • Single or multi-use license
  • Free license for KAYA Instruments CoaXPress Mezzanine card users
  • Soft IP core: RTL-encrypted source code, synthesis scripts, etc.
  • Comprehensive documentation package
  • Support for Altera, Xilinx, and PolarFire from Microsemi FPGAs
  • Language: Verilog HDL
  • Simulation environment: ModelSim
